New Holland TS6.120 Specs ( 2012-Present )

Name: New Holland TS6.120
Brand: New Holland

Overview

The New Holland TS6.120 is a row-crop farm tractor in production since 2012, powered by a 4.5L FPT four-cylinder turbocharged diesel engine rated at 118 gross horsepower. It features a Category II rear hitch with a 3,600-pound lift capacity and is available in multiple configurations, including two-wheel or four-wheel drive and standard or high-crop variants.

Ideal Applications

Nebraska Test Performance: Actual tested performance recorded a maximum PTO output of 104.24 hp and a maximum drawbar pull capacity of 8,821 lbs.

Transmission and Drive Configuration: The tractor is equipped with either an 8-speed mechanical or power shuttle transmission, or a 16-speed DualPower system with 16 forward and 8 reverse gears.

Hydraulic and Hitch Specifications: The hydraulic system provides a 13 gpm pump flow to 2 or 4 rear valves, supporting a Rear Type II hitch with top link draft sensing.

Production

Description	Row-Crop tractor
Manufacturer	New Holland
Original price	$48,822 (2014 Mech Shuttle ROPS 2WD )

Engine

Engine type	FPT 4.5L 4-cyl diesel
Fuel tank	39.6 gal (149.9 L)
Bore/Stroke	4.094x5.197 inches (104 x 132 mm)
Description	FPT / turbocharged intercooled diesel / 4-cylinder / liquid-cooled
Displacement	273.7 ci (4.5 L)
Emissions	Tier III
Power (gross)	118 hp (88.0 kW)
Starter	electric
Starter volts	12
Engine (gross)	118 hp (88.0 kW)
PTO (claimed)	96 hp (71.6 kW)

Transmission

Clutch	dry disc / wet disc
Gears	8 forward and reverse / 8 forward and reverse / 16 forward and 8 reverse
Transmission	DualPower
Type	mechanical shuttle / power shuttle
Transmission type	8-speed mechanical shuttle / 8-speed power shuttle / 16-speed
Transmission type	8-speed mechanical shuttle / 8-speed power shuttle / 16-speed

Mechanical

Cab	Two-post foldable ROPS. Cab optional with air-conditioning.
Drive type	Two- or four-wheel drive

Hydraulics

Pump flow	13 gpm (49.2 lpm)
Rear valves	2 to 4
Steering flow	9 gpm (34.1 lpm)

Hitch

Control	top link draft sensing
Rear lift (at 24"/610mm)	3600 lbs (1632 kg)
Rear Type	II

PTO

Clutch	wet disc
Rear PTO	independent
Rear PTO Type	540/1000

Electrical

Battery CCA	950
Battery volts	12
Charging amps	120
Charging system	alternator
Ground	negative

Dimensions & Tires

Description	Flange rear axle / Bar rear axle
Front tread	56 to 80 inches (2WD) (142 to 203 cm) / 64 to 80 inches (4WD) (162 to 203 cm)
Rear tread	64 to 80 inches (flange) (162 to 203 cm) / 62 to 92 inches (bar) (157 to 233 cm)
Weight	7524 to 8847 pounds

New Holland TS6.120 Height

Cab	111 inches (281 cm)
Exhaust	116 inches (294 cm)
ROPS	116 inches (294 cm)

New Holland TS6.120 Weight

Shipping	7524 lbs (2WD ROPS) (3412 kg)

New Holland TS6.120 attachments

Description	front-end loader

Variants

TS6.120	row-crop
TS6.120HC	high-crop

Nebraska Tractor Test Results

Test #2157A

Download PDF

Test Date: September 7 - 9, 2016

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Rated Engine Speed

102.55 hp

N/A lb/hp·hr

Standard PTO Speed

104.24 hp

@ 540 rpm PTO

Torque Statistics

Maximum Torque	366 lb-ft (496 Nm)
Torque Rise	49.5%

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM	PTO RPM	Fuel gal/hr	Fuel L/hr	DEF gal/hr	DEF L/hr
Rated Engine Speed	102.55	76.47	2201	628	6.40	24.23	0.40	1.52
Standard PTO Speed (1000 rpm)	104.24	77.74	1890	540	5.94	22.48	0.38	1.42

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
102.55	2201	6.40	0.44	16.02	0.40
88.78	2238	5.94	0.47	14.96	0.35
67.59	2268	4.86	0.50	13.91	0.27
45.61	2298	3.93	0.60	11.62	0.19
23.09	2324	3.19	0.97	7.24	0.13
0.91	2348	2.27	17.56	0.40	0.07

Unballasted Front Drive Engaged 1850 Engine RPM

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr
6th (L3R) Gear	76.34	8,815	3.25	2219	14.90	0.05	76	183	28.73	12.38	0.57
7th (L4T) Gear	83.41	8,542	3.67	2164	13.10	0.04	72	185	28.71	13.07	0.54
8th (L4R) Gear	88.41	7,477	4.43	2050	9.30	0.04	73	183	28.72	14.29	0.49
9th (H1T) Gear	87.78	7,299	4.51	2000	8.80	0.04	72	183	28.71	14.29	0.49
10th(H1R) Gear	91.52	6,392	5.37	1900	6.90	0.04	71	183	28.71	15.31	0.46
11th (H2T) Gear	91.10	5,107	6.69	1850	5.20	0.04	76	184	28.70	15.49	0.45
12th (H2R) Gear	92.21	4,161	8.31	1850	3.80	0.04	78	183	28.70	15.75	0.45

Fuel Consumption Characteristics (Unballasted) Front Drive Engaged

Click column headers to sort

Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Condition	Fuel Hp Hr Gal	Fuel Lb Hp Hr
87.99	6,814	4.84	2200	7.70	0.04	72	183	28.72	Power at Rated Engine Speed—8th (L4R) Gear	13.75	0.51
69.29	5,097	5.10	2249	5.00	0.05	81	183	28.68	75% of Pull at Rated Engine Speed—8th (L4R) Gear	12.75	0.55
48.03	3,406	5.29	2283	2.90	0.05	82	183	28.68	50% of Pull at Rated Engine Speed—8th (L4R) Gear	10.89	0.64
69.62	5,132	5.09	1766	5.10	0.04	83	182	28.65	75% of Pull at Reduced Engine Speed—10th (H1R) Gear	15.34	0.46
48.19	3,413	5.30	1798	2.90	0.04	82	181	28.67	50% of Pull at Reduced Engine Speed—10th (H1R) Gear	13.70	0.51

Maximum Power In Selected Gears (Unballasted) Front Drive Engaged

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr
6th (L3R) Gear	76.27	8,821	3.25	2219	15.00	0.05	76	183	28.72	12.33	0.57
7th (L4T) Gear	83.49	8,301	3.77	2200	12.00	0.05	72	184	28.72	13.04	0.54
8th (L4R) Gear	87.99	6,814	4.84	2200	7.70	0.04	72	183	28.72	13.75	0.51
9th (H1T) Gear	87.45	6,481	5.06	2200	7.10	0.04	72	183	28.71	13.64	0.51
10th(H1R) Gear	90.03	5,335	6.33	2200	5.30	0.04	72	183	28.71	14.04	0.50
11th (H2T) Gear	89.22	4,151	8.06	2200	3.80	0.05	77	185	28.71	14.00	0.50

Category: II Quick Attach: none

Single Pump System

Single Outlet Set

Sustained Pressure	2,223 psi
Flow Rate (min press)	N/A gpm
Max Power	13.00 hp

Two Outlet Sets Combined

Sustained Pressure	2,268 psi
Flow Rate (min press)	N/A gpm
Max Power	13.50 hp

Hitch Dimensions (No Load)

Dimension	Inches	mm

Engine

Make	F.P.T NEF Diesel
Type	Four cylinder vertical with turbocharger, air to air intercooler and D.E.F. (diesel exhaust fluid) exhaust treatment
Displacement	274 cu in (4485 ml)
Compression Ratio	17.0 to 1
Rated Engine Speed	2200 rpm
Air Cleaner	two paper elements
Exhaust	DOC (diesel oxidation catalyst) and SCR (selective catalyst reduction) integrated within a vertical muffler

Chassis

Type	front wheel assist
Steering	hydrostatic
Transmission	selective gear fixed ratio with partial (2) range operator controlled powershift
Speeds	16 forward (18.98 mph max)
Wheelbase	99.30 in (2521 mm)
Front Tread Width	60.8 to 88.1 in
Rear Tread Width	64.0 to 78.0 in
Brakes	single wet disc operated by two foot pedals which can be locked together
Hydraulic Control	direct engine drive
Unladen Tractor Mass	10,505 lbs ( 4,765 kg )

Consumables

Fuel	No. 2 Diesel
DEF Fluid	32% aqueous urea solution

Sound Levels

Bystander	86.20 dB(A)
At No Load In 8th Gear Fwd Disengaged	79.90 dB(A)
At No Load In 8th Gear Fwd Engaged	79.80 dB(A)

Tires & Tracks

Rear Tires	Two 18.4-38; 8 ply; 16 psi (110 kPa)
Front Tires	Two 14.9-28; 6 ply; 16 psi (110 kPa)
Height of Drawbar	23.50 in (595 mm)

Static Weight

Rear	6,260 lbs
Front	4,420 lbs
Total	10,680 lbs
