Production
| Description | Row-Crop tractor / Built in Bierne, France |
|---|---|
| Manufacturer | Kubota |
Engine
| Engine type | Kubota 6.1L 4-cyl diesel |
|---|---|
| Exhaust fluid (DEF) | 10 gal (37.9 L) |
| Fuel tank | 87.2 gal (330.1 L) |
| Bore/Stroke | 4.65x5.51 inches (118 x 140 mm) |
| Description | Kubota V6108-CR / turbocharged intercooled diesel / 4-cylinder 16-valve / liquid-cooled |
| Displacement | 373.7 ci (6.1 L) |
| Emissions | Stage IV |
| Maximum Power (gross) | 150 hp (111.9 kW) |
| Rated Power (gross) | 130 hp (96.9 kW) |
| Rated RPM | 1900 |
| Starter | electric |
| Starter volts | 12 |
| Torque | 443 lb-ft (600.7 Nm) |
| Torque RPM | 1500 |
| Drawbar (tested) | 84.54 hp (63.0 kW) |
| Engine (gross) | 130 hp (96.9 kW) |
| Engine (max) | 150 hp (111.9 kW) |
| PTO (tested) | 122.40 hp (91.3 kW) |
Transmission
| Clutch | electro-hydraulic wet disc |
|---|---|
| Description | Six power shift gears in five synchronized ranges with shuttle. |
| Gears | 30 forward and 15 reverse / infinite forward and reverse / 54 forward and 27 reverse |
| Transmission | KVT |
| Type | 6-speed power shift / infinitely variable transmission / creeper |
| Description | infinitely variable transmission |
| Transmission type | 30-speed 6-speed power shift / 54-speed creeper |
| Description | infinitely variable transmission |
| Transmission type | 30-speed 6-speed power shift / 54-speed creeper |
Mechanical
| Cab | Cab standard with air-conditioning. |
|---|---|
| Description | Power steering / Hydraulic wet disc brakes |
| Drive type | Four-wheel drive |
Hydraulics
| Pump flow | 21.1 gpm (open center) (79.9 lpm) |
|---|---|
| Type | open center |
Hitch
| Control | lower-link draft sensing |
|---|---|
| Front lift | 8598 lbs (3900 kg) |
| Rear lift (at ends) | 20723 lbs (9399 kg) |
| Rear Type | III |
PTO
| Engine RPM | 540E@1608 |
|---|---|
| Front PTO | independent |
| Front PTO Type | 1000 |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
Electrical
| Battery volts | 12 |
|---|---|
| Charging system | alternator |
| Ground | negative |
Dimensions & Tires
| Height | 119.3 inches (303 cm) |
|---|---|
| Length | 187.8 inches (477 cm) |
| Shipping weight | 13889 lbs (6300 kg) |
| Wheelbase | 107.1 inches (272 cm) |
| Width | 98.4 inches (249 cm) |
| Front tire | 540/65R28 |
| Rear tire | 650/65R38 |
| Weight | 13889 lbs (6300 kg) |
| Wheelbase | 107.1 inches (272 cm) |
| Standard tires (ag) | Front: 540/65R28. Rear: 650/65R38 |
OCED Tractor Test 2214
| Description | Diesel Power shift 4WDOctober 29 - November 7, 2019Link: OCED Tractor Test 2214 file / PTO performance / Drawbar performance |
|---|---|
| Fuel use | 7.4 gal/hour (28.0 l/hour) / 7.0 gal/hour (26.5 l/hour) / 7.5 gal/hour (28.4 l/hour) / 6.1 gal/hour (23.1 l/hour) |
| Max power | 122.40 hp (91.3 kW) / 84.54 hp (63.0 kW) |
| Max pull | 14617 lbs (6630 kg) |
| Power at rated engine speed | 104.73 hp (78.1 kW) |
| Power at rated PTO speed | 119.16 hp (88.9 kW) |
References
| Description | M7002 Series published in 2018, by Kubota / M7-2 Series published in 2021, by Kubota |
|---|
