Overview
The Kubota M110GX is a powerful 109.5 hp row-crop tractor featuring a 3.8L turbocharged diesel engine and a versatile 24 or 32-speed Intelli-Shift transmission. Designed for operator comfort and efficiency, it comes standard with the Grand X Cab and a high-capacity hydraulic system capable of lifting 6,834 lbs at the rear hitch.
Ideal Applications
Row-Crop Production:
The adjustable rear tread width up to 80.3 inches and electro-hydraulic differential locks make this tractor well-suited for precise navigation and traction in row-crop fields.
Material Handling:
Equipped with a dedicated front-end loader attachment and a 18.7 gpm hydraulic pump, the M110GX provides the flow and lift capacity required for intensive loading and lifting tasks.
Heavy Implement Operation:
With a 96 hp PTO and electronic lower-link draft control, this machine efficiently manages power-demanding rear implements and heavy Category II attachments.
Production
| Description | Row-Crop tractor / Original price was $70,010 in 2014 |
|---|---|
| Manufacturer | Kubota |
Engine
| Engine type | Kubota 3.8L 4-cyl diesel |
|---|---|
| Fuel tank | 50.2 gal (190.0 L) |
| Air cleaner | dual dry element |
| Bore/Stroke | 3.94x4.72 inches (100 x 120 mm) |
| Description | Kubota V3800-TI-CRS / turbocharged and intercooled diesel / 4-cylinder 16-valve / liquid-cooled |
| Displacement | 230 ci (3.8 L) |
| Emission control | exhaust gas recirculation and diesel particulate filter (DPF) (EGR) |
| Emissions | Interim Tier IV |
| Fuel system | common rail direct injection |
| Power | 109.5 hp (81.7 kW) |
| Rated RPM | 2600 |
| Starter | electric |
| Starter volts | 12 |
| PTO (claimed) | 96 hp (71.6 kW) |
Transmission
| Clutch | electro-hydraulic wet disc / electro-hydraulic wet disc |
|---|---|
| Description | Eight power shift gears in three ranges. Power shuttle. |
| Gears | 24 forward and reverse / 32 forward and reverse |
| Transmission | Intelli-Shift / Intelli-Shift Creeper |
| Type | eight-speed power shift |
| Transmission type | 24-speed eight-speed power shift / 32-speed |
| Transmission type | 24-speed eight-speed power shift / 32-speed |
Mechanical
| Cab | Grand X Cab standard with air-conditioning. |
|---|---|
| Description | Power steering / Hydraulic wet disc brakes |
| Differential lock | electro-hydraulic front and rear |
| Drive type | Four-wheel drive |
Hydraulics
| Pump flow | 18.7 gpm (70.8 lpm) |
|---|---|
| Steering flow | 16 gpm (60.6 lpm) |
| Valves | 2 to 4 |
Hitch
| Control | electronic lower-link draft control |
|---|---|
| Rear Arms | telescopic lower link ends |
| Rear lift (at 24"/610mm) | 6834 lbs (3099 kg) |
| Rear Type | II |
PTO
| Clutch | hydraulic wet disc |
|---|---|
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
Electrical
| Battery AH | 100 |
|---|---|
| Battery CCA | 900 |
| Battery volts | 12 |
| Charging amps | 80 |
| Charging system | alternator |
| Ground | negative |
Dimensions & Tires
| Front axle | 4WD |
|---|---|
| Front tread | 62.2 to 66.1 inches (157 to 167 cm) |
| Ground clearance | 19.5 inches (49 cm) |
| Height | 111.8 inches (283 cm) |
| Length | 165.4 inches (420 cm) |
| Rear tread | 60.2 to 80.3 inches (152 to 203 cm) |
| Weight | 9216 lbs (4180 kg) |
| Wheelbase | 95.9 inches (243 cm) |
| Width | 82.7 inches (210 cm) |
| Front tire | 13.6R24 |
| Rear tire | 18.4R34 |
| Weight | 9216 lbs (4180 kg) |
| Wheelbase | 95.9 inches (243 cm) |
| Ag front | 13.6R24 |
| Ag rear | 18.4R34 |
Kubota M110GX attachments
| Description | front-end loader |
|---|
M110GX Serial Number Location
| Description | Serial number decal on the right side of the M110GX tractor frame, above the front axle. |
|---|
Nebraska Tractor Test Results
Test #2063
Test Date:
June 6 - December 10, 2013
Location:
Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln Nebraska 68583-0832
This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.
Maximum Power & Fuel Consumption
Rated Engine Speed
97.50 hp
N/A lb/hp·hr
Standard PTO Speed
91.71 hp
@ 541 rpm PTO
Torque Statistics
| Maximum Torque | 237 lb.-ft. (321 Nm) at 1601 rpm |
|---|---|
| Torque Rise | 20.2% |
PTO Power Curve
Maximum Power & Fuel Consumption Details
| Condition | HP | kW | RPM | PTO RPM | Fuel gal/hr | Fuel L/hr |
|---|---|---|---|---|---|---|
| Rated Engine Speed | 97.50 | 72.71 | 2601 | 637 | 6.08 | 23.03 |
| Standard PTO Speed (1000 rpm) | 91.71 | 68.39 | 2205 | 541 | 5.42 | 20.53 |
Varying Power & Fuel Consumption
Click column headers to sort
| Power | RPM | gal/hr | lb/hp·hr | hp·hr/gal | DEF gal/hr |
|---|---|---|---|---|---|
| 97.50 | 2601 | N/A | 0.44 | 16.03 | N/A |
| 83.89 | 2635 | N/A | 0.46 | 15.17 | N/A |
| 63.89 | 2668 | N/A | 0.51 | 13.83 | N/A |
| 43.13 | 2702 | N/A | 0.61 | 11.61 | N/A |
| 21.83 | 2729 | N/A | 0.90 | 7.85 | N/A |
| 1.43 | 2761 | N/A | 9.10 | 0.77 | N/A |
