John Deere 6130D Specs ( 2008-2016 )

Name: John Deere 6130D
Brand: John Deere

Overview

The John Deere 6130D is a utility tractor manufactured in Saltillo, Mexico, between 2008 and 2016. It is powered by a 4.5L 4-cylinder intercooled turbocharged diesel engine and features either a 9-speed PowrReverser or Top Shaft Synchronized transmission. The model is equipped with a Category II rear hitch and an open center hydraulic system providing 17.6 gpm of pump flow.

Ideal Applications

Nebraska Tested Performance: In official Nebraska testing, the tractor achieved a maximum PTO output of 111.98 horsepower and a maximum drawbar pull of 8,929 pounds.

Transmission Configuration: This model is available with either a 9-speed PowrReverser transmission featuring a power shuttle or a 9-speed Top Shaft Synchronized (TSS) transmission with 3 reverse gears.

Hitch and Hydraulic Capacity: The mechanical Category II rear hitch is rated for a lift capacity of 6,800 pounds at 24 inches, operating on a hydraulic system with 2,830 psi of pressure.

Production

Description	Utility tractor / Built in Saltillo, Mexico
Manufacturer	John Deere
Original price	$53,639 (2011)

Engine

Engine type	John Deere 4.5L 4-cyl diesel
Bore/Stroke	4.20x5.00 inches (107 x 127 mm)
Compression	19:1
Coolant capacity	17.4 qts (16.5 L)
Description	John Deere 4045H PowerTech E / intercooled turbocharged diesel / 4-cylinder 8-valve / liquid-cooled
Displacement	276 ci (4.5 L)
Emissions	Tier 3
Exhaust valve clearance	0.018 inches (0.457 mm)
Firing order	1-3-4-2
Fuel system	Denso electronic high-pressure common rail
Idle RPM	900-2200
Intake valve clearance	0.014 inches (0.356 mm)
Rated Power (gross)	129.8 hp (96.8 kW)
Rated RPM	2100
Starter volts	12
Torque	387 lb-ft (524.8 Nm)
Torque RPM	1500
Oil capacity	15.85 qts (15.0 L)
Oil change	250 h
Drawbar (tested)	91.70 hp (68.4 kW)
Engine (gross)	129.8 hp (96.8 kW)
PTO (claimed)	105 hp (78.3 kW)
PTO (tested)	109.64 hp (81.8 kW)

Transmission

Clutch	hydraulic wet disc / dry disc
Description	Three gears (1-3) in each of three ranges (A-C) plus left-hand reverser. Forward/reverse powershift. Synchronized shift between gears with clutch. Shifts between ranges are unsynchronized: the tractor must be stopped and clutch used to shift range. / Three gears (1-3) plus reverse (R) in each of three ranges (A-C). Shifts between gears, including to reverse, are synchronized using the clutch. Shifts between ranges are not synchronized, the operator must stop the tractor and use the clutch.
Gears	9 forward and reverse / 9 forward and 3 reverse
Oil capacity	61.2 qts (57.9 L) / 61.2 qts (57.9 L)
Transmission	John Deere PowrReverser / John Deere Top Shaft Syncronized (TSS)
Type	partially synchronized with power shuttle / partially synchronzied
Transmission type	9-speed partially synchronized with power shuttle / 9-speed partially synchronzied
Transmission type	9-speed partially synchronized with power shuttle / 9-speed partially synchronzied

Mechanical

Description	Independent mechanical wet disc brakes / Folding 2-post ROPS or cab with heat and A/C
Drive type	Four-wheel drive
Steering	hydrostatic power

Capacity

Front axle	6.9 qts (6.5 L)
Front hubs	2.1 qts (each) (2.0 L)
Fuel	41.7 gal (157.8 L)
Hydraulic system	15.3 gal (57.9 L)

Hydraulics

Capacity	15.3 gal (57.9 L)
Pressure	2830 psi (195.1 bar)
Pump flow	17.6 gpm (66.6 lpm)
Steering flow	6.9 gpm (26.1 lpm)
Type	open center
Valves	2 to 3

Hitch

Control	mechanical lower link
Rear lift (at 24"/610mm)	6,800 lbs (3084 kg)
Rear Type	II

PTO

Clutch	dry disc
Engine RPM	540@2100
Rear PTO	independent
Rear PTO Type	540/1000 (1.375)

Electrical

Battery AH	180
Battery CCA	925
Battery Group	31
Battery volts	12
Charging amps	70 (ROPS)
Charging system	alternator
Ground	negative

Dimensions & Tires

Clearance (front axle)	18 inches (45 cm)
Front tread	63.6 to 79.4 inches (161 to 201 cm)
Height (cab)	107.5 inches (273 cm)
Height (exhaust)	106 inches (269 cm)
Length	166 inches (421 cm)
Rear axle	72 inch length (flange) (1828 mm)
Rear tread	59.5/63.5/67.6/71.3/75.4/79.4 inches (151/161/171/181/191/201 cm)
Wheelbase	92.5 inches (234 cm)
Width	72 inches (182 cm)
Front tire	14.9-24
Rear tire	18.4-34
Weight	8730 to 9920 pounds
Wheelbase	92.5 inches (234 cm)
Optional tires (ag)	Front: 14.9-24. Rear: 18.4-38
Standard tires (ag)	Front: 14.9-24. Rear: 18.4-34

6130D Serial Number Location

Description	Serial number plate on the right side of the tractor frame, above the front axle.

John Deere 6130D Weight

Ballasted	12,370 lbs (5611 kg)
Operating	9,920 lbs (cab) (4499 kg)
Shipping	8,730 lbs (ROPS) (3959 kg)

John Deere 6130D attachments

Description	front-end loader

OCED Tractor Test 1950

Description	Diesel 9-speed 4WDMarch 30 - April 21, 2009Link: OCED Tractor Test 1950 file / PTO performance / Drawbar performance
Fuel use	6.7 gal/hour (25.4 l/hour) / 6.7 gal/hour (25.4 l/hour) / 6.8 gal/hour (25.7 l/hour) / 6.8 gal/hour (25.7 l/hour)
Max power	109.64 hp (81.8 kW) / 91.70 hp (68.4 kW)
Max pull	10,426 lbs (4729 kg)
Power at rated engine speed	108.29 hp (80.8 kW)
Power at rated PTO speed	109.13 hp (81.4 kW)

References

Description	All-New 6D Series Tractors published in 2008, by John Deere

Speeds

Description	With 18.4-34 rear tires. / With 18.4-34 rear tires.

Nebraska Tractor Test Results

Test #2057

Download PDF

Test Date: March 27 - April 11, 2013

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln, Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Max Power (1 Hour)

111.98 hp

@ 1900 rpm

Rated Engine Speed

107.92 hp

N/A lb/hp·hr

Standard PTO Speed

109.20 hp

@ N/A rpm PTO

Torque Statistics

Maximum Torque	347 lb-ft (470 Nm)
Torque Rise	38.4%
At Engine RPM	1500 rpm

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM	Fuel gal/hr	Fuel L/hr
Maximum Power (1 Hour)	111.98	83.50	1900	6.27	23.74

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
104.94	2200	6.32	0.42	16.60	N/A
91.73	2261	5.88	0.45	15.60	N/A
69.53	2285	4.87	0.49	14.29	N/A
46.66	2300	3.79	0.57	12.29	N/A
23.34	2301	2.79	0.84	8.35	N/A
2.33	2300	1.91	5.74	1.22	N/A

Unballasted Front Drive Engaged 1900 Engine RPM

Click column headers to sort

Gear	Power	kW	Pull (lbs)	Pull (kN)	Speed	RPM	Slip	Air °F	Air °C	Cool °F	Cool °C	Barometer Inch Hg	Barometer Kpa	Fuel Consumption Hp Hr Gal	Fuel Consumption Kg Kw H	Fuel Consumption Kw H L	Fuel Consumption Lb Hp Hr	Speed Km H
3rd (A3) Gear	72.25	53.88	8,927	39.71	3.04	2267	14.60	52	11	183	84	29.04	98.34	12.88	0.33	2.54	0.54	4.88
4th (B1) Gear	89.43	66.69	8,406	37.39	3.99	2205	12.80	47	8	183	84	29.06	98.41	14.30	0.30	2.82	0.49	6.42
5th (B2) Gear	96.95	72.30	7,435	33.07	4.89	1900	10.10	49	9	184	84	29.06	98.41	15.43	0.28	3.04	0.45	7.87
6th (B3) Gear	99.15	73.94	5,712	25.41	6.51	1900	6.70	50	10	183	84	29.05	98.37	15.79	0.27	3.11	0.44	10.48

Unballasted Front Drive Engaged Fuel Consumption Characteristics

Click column headers to sort

Power	kW	Pull (lbs)	Pull (kN)	Speed	RPM	Slip	Air °F	Air °C	Cool °F	Cool °C	Barometer Inch Hg	Barometer Kpa	Condition	Fuel Consumption Hp Hr Gal	Fuel Consumption Kg Kw H	Fuel Consumption Kw H L	Fuel Consumption Lb Hp Hr	Speed Km H
93.07	69.40	5,976	26.58	5.84	2200	7.30	48	9	183	84	29.06	98.41	Maximum Power - 5th (B2) Gear	14.74	0.29	2.90	0.48	9.40
73.50	54.81	4,467	19.87	6.17	2272	5.10	57	14	181	83	29.00	98.21	75% of Pull at Maximum Power - 5th (B2) Gear	13.39	0.32	2.64	0.52	9.93
49.97	37.26	2,956	13.15	6.34	2296	3.40	57	14	180	82	29.00	98.21	50% of Pull at Maximum Power - 5th (B2) Gear	11.43	0.37	2.25	0.61	10.20
73.39	54.73	4,490	19.97	6.13	1757	5.00	58	15	182	83	29.00	98.21	75% of Pull at Reduced Engine Speed - 6th (B3) Gear	15.34	0.28	3.02	0.46	9.87
50.00	37.28	2,948	13.11	6.36	1790	3.30	58	14	178	81	29.00	98.21	50% of Pull at Reduced Engine Speed - 6th (B3) Gear	13.69	0.31	2.70	0.51	10.24

Unballasted Front Drive Engaged Maximum Power In Selected Gears

Click column headers to sort

Gear	Power	kW	Pull (lbs)	Pull (kN)	Speed	RPM	Slip	Air °F	Air °C	Cool °F	Cool °C	Barometer Inch Hg	Barometer Kpa	Fuel Consumption Hp Hr Gal	Fuel Consumption Kg Kw H	Fuel Consumption Kw H L	Fuel Consumption Lb Hp Hr	Speed Km H
3rd (A3) Gear	72.14	53.80	8,929	39.72	3.03	2267	14.80	53	11	183	84	29.04	98.34	12.66	0.34	2.49	0.55	4.88
4th (B1) Gear	89.40	66.67	8,392	37.33	4.00	2203	12.70	46	8	183	84	29.06	98.41	14.13	0.30	2.78	0.50	6.43
5th (B2) Gear	93.07	69.40	5,976	26.58	5.84	2200	7.30	48	9	183	84	29.06	98.41	14.74	0.29	2.90	0.48	9.40
6th (B3) Gear	93.55	69.76	4,574	20.35	7.67	2200	5.10	50	10	184	84	29.05	98.37	14.77	0.29	2.91	0.48	12.34

Category: II Quick Attach: No

Two Outlet Sets Combined

Sustained Pressure	2,710 psi
Flow Rate (min press)	20.40 gpm
Max Power	30.70 hp

Single Outlet Set

Sustained Pressure	2,646 psi
Flow Rate (min press)	20.70 gpm
Max Power	29.90 hp

Engine

Make	John Deere Diesel
Type	Four cylinder vertical with turbocharger and air to air intercooler
Displacement	276 cu in (4525 ml)
Compression Ratio	19.0 to 1
Rated Engine Speed	2200 rpm
Air Cleaner	two paper elements and aspirator
Exhaust	regenerative particulate filter integrated within an underhood muffler

Chassis

Type	front wheel assist
Steering	hydrostatic
Transmission	selective gear fixed ratio
Wheelbase	96.50 in (2450 mm)
Front Tread Width	60.1 (1527 mm) to 80.3 (2039 mm) in
Rear Tread Width	59.5 (1512 mm) to 79.2 (2012 mm) in
Brakes	wet multiple disc mechanically operated by two foot pedals that can be locked together
Hydraulic Control	direct engine drive
Unladen Tractor Mass	10,000 lbs ( 4,536 kg )

Tires & Tracks

Rear Tires	18.4-38
Front Tires	14.9-24
Height of Drawbar	18.00 in (455 mm)

Static Weight

Rear	6,355 lbs
Front	3,820 lbs
Total	10,175 lbs
