John Deere 6105E Specs ( 2016-Present )
Overview
The John Deere 6105E is a utility farm tractor manufactured in Saltillo, Mexico, and has been in production since 2016. It is powered by a 4.5L 4-cylinder Tier IV diesel engine rated at 105 gross horsepower and features an open center hydraulic system with a 20 gpm pump flow. The tractor is available in two-wheel or four-wheel drive configurations and is equipped with either a 12-speed or 24-speed PowrReverser transmission.
Ideal Applications
Tested PTO and Engine Performance:
The 4.5L 4-cylinder engine utilizes a wastegate turbocharger and air-to-air aftercooling to deliver a tested maximum PTO output of 93.3 horsepower at a rated 2200 RPM.
Transmission and Drivetrain Layout:
Equipped with a PowrReverser transmission, the drivetrain features synchronized range upshifts for ranges B-C and C-D and a wet disc clutch system.
Chassis and Hitch Specifications:
This model features a Category 2 drawbar, telescopic draft arms, and a flange rear axle, with a listed maximum ballast weight of 14,250 lbs and a maximum drawbar capacity of 5,500 lbs.
Production
| Description | Utility tractor / Built in Saltillo, Mexico |
|---|---|
| Manufacturer | John Deere |
| Original price | $63,600 (2015 ROPS ) |
Engine
| Engine type | John Deere 4.5L 4-cyl diesel |
|---|---|
| Air cleaner | dual stage dry |
| Bore/Stroke | 4.17x5.00 inches (106 x 127 mm) |
| Compression | 16.8:1 |
| Description | John Deere PowerTech PWL / wastegate turbocharger with air-to-air aftercooling diesel / 4-cylinder 16-valve / inline |
| Displacement | 275 ci (4.5 L) |
| Emission control | cooled exhaust-gas recirculation |
| Emissions | Tier IV |
| Fuel system | electronic high-pressure common rail |
| Idle RPM | 900-2275 |
| Operating RPM | 1800-2200 |
| Rated Power (gross) | 105 hp (78.3 kW) |
| Rated RPM | 2200 |
| Starter | electric |
| Starter volts | 12 |
| Torque | 318 lb-ft (431.2 Nm) |
| Torque RPM | 1600 |
| Engine (gross) | 105 hp (78.3 kW) |
| PTO (claimed) | 89 hp (66.4 kW) |
Transmission
| Clutch | wet disc / wet disc |
|---|---|
| Description | Four gears (1-4) in four ranges (A-D) with shuttle lever. Range upshifts B-C and C-D, plus downshift D-C, are synchronized. |
| Gears | 12 forward and reverse / 24 forward and 12 reverse |
| Transmission | PowrReverser / PowrReverser Hi-Lo |
| Type | two-speed power shift |
| Transmission type | 12-speed / 24-speed two-speed power shift |
| Transmission type | 12-speed / 24-speed two-speed power shift |
Mechanical
| 4WD Differential lock | limited-slip front |
|---|---|
| Cab | Two-post foldable ROPS. Cab optional with air-conditioning. AutoTrac ((Optional steering kit)) |
| Differential lock | mechanical rear |
| Drive type | Two- or four-wheel drive |
| Final drives | inboard planetary |
Hydraulics
| Pressure | 2828 psi (195.0 bar) |
|---|---|
| Pump flow | 20 gpm (75.7 lpm) |
| Type | open center |
| Valves | 2 to 3 |
Hitch
| Control | draft sensing OptOptional |
|---|---|
| Drawbar | Cat. 2 |
| Rear Arms | telescopic draft arms |
| Rear lift (at 24"/610mm) | 550 lbs (249 kg) |
| Rear Type | II |
PTO
| Engine RPM | 540@2085 |
|---|---|
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
Electrical
| Battery volts | 12 |
|---|---|
| Ground | negative |
Dimensions & Tires
| 2WD Front tread | 60.4 to 80.4 inches (153 to 204 cm) |
|---|---|
| 2WD Wheelbase | 96.7 inches (245 cm) |
| 4WD Front tread | 59.7 to 79.4 inches (151 to 201 cm) |
| 4WD Wheelbase | 96.5 inches (245 cm) |
| Description | Flange rear axle |
| 2WD Wheelbase | 96.7 inches (245 cm) |
| 4WD Wheelbase | 96.5 inches (245 cm) |
6105E Serial Number Location
| Description | Serial number plate on the right side of the 6105E tractor frame, above the front axle. |
|---|
John Deere 6105E Weight
| Ballasted | 14250 lbs (6463 kg) |
|---|---|
| Max capacity | 17636 lbs (7999 kg) |
| Max Drawbar | 5500 lbs (2494 kg) |
Nebraska Tractor Test Results
Test #2143
Test Date:
April 13 - 15, 2016
Location:
Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln Nebraska 68583-0832
This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.
Maximum Power & Fuel Consumption
Max Power (1 Hour)
93.30 hp
@ 1900 rpm
Rated Engine Speed
83.94 hp
N/A lb/hp·hr
Standard PTO Speed
91.22 hp
@ N/A rpm PTO
Torque Statistics
| Maximum Torque | 285 lb-ft (386 Nm) |
|---|---|
| Torque Rise | 42.0% |
| At Engine RPM | 1400 rpm |
PTO Power Curve
Maximum Power & Fuel Consumption Details
| Condition | HP | kW | RPM | Fuel gal/hr | Fuel L/hr | DEF gal/hr | DEF L/hr |
|---|---|---|---|---|---|---|---|
| Maximum Power (1 Hour) | 93.30 | 69.57 | 1900 | 5.34 | 20.22 | 0.22 | 0.83 |
Varying Power & Fuel Consumption
Click column headers to sort
| Power | RPM | gal/hr | lb/hp·hr | hp·hr/gal | DEF gal/hr |
|---|---|---|---|---|---|
| 83.94 | 2200 | 5.44 | 0.45 | N/A | 0.18 |
| 72.25 | 2225 | 4.95 | 0.48 | N/A | 0.16 |
| 54.75 | 2248 | 4.07 | 0.52 | N/A | 0.10 |
| 37.00 | 2277 | 3.37 | 0.64 | N/A | 0.05 |
| 18.61 | 2299 | 2.60 | 0.98 | N/A | 0.00 |
| 2.21 | 2300 | 2.00 | 6.34 | N/A | 0.00 |
