John Deere 6105D Specs ( 2013-2016 )

Name: John Deere 6105D
Brand: John Deere

Overview

The John Deere 6105D is a utility farm tractor produced in Saltillo, Mexico, between 2013 and 2016, featuring a 4.5L 4-cylinder PowerTech PWX engine. It is equipped with a choice of 9, 12, or 24-speed partially synchronized transmissions and was available in both two-wheel and four-wheel drive configurations with optional air-conditioned cabs.

Ideal Applications

Engine and PTO Performance: The 4.5L diesel engine produced a tested maximum of 91.22 hp at the PTO and 312 lb-ft of torque at 1600 RPM during Nebraska Tractor Test 2055.

Transmission and Powertrain Layout: Standardized to a 12-speed PowrReverser in 2014, the transmission system utilizes three ranges with a power shuttle and requires the tractor to be stationary for range shifts.

Hydraulic and Hitch Capacity: The open center hydraulic system provides a pump flow of 20 gpm at 2828 psi, supporting a Category II rear hitch with a lift capacity of 5500 lbs at 24 inches.

Production

Description	Utility tractor / Built in Saltillo, Mexico
Manufacturer	John Deere
Original price	$47,396 (2014 ROPS 2WD )

Engine

Engine type	John Deere 4.5L 4-cyl diesel
Fuel tank	41.7 gal (157.8 L)
Bore/Stroke	4.17x5.00 inches (106 x 127 mm)
Compression	19:1
Coolant capacity	18.7 qts (17.7 L)
Description	John Deere PowerTech PWX / wastegate turbocharger with aftercooled diesel / 4-cylinder 16-valve / liquid-cooled
Displacement	275 ci (4.5 L)
Emission control	cooled exhaust gas recirculation
Emissions	Interim Tier IV
Oil capacity	15.85 qts (15.0 L)
Rated Power (gross)	105 hp (78.3 kW)
Rated RPM	2200
Starter	electric
Starter volts	12
Torque	312 lb-ft (423.1 Nm)
Torque RPM	1600
Engine (gross)	105 hp (78.3 kW)
PTO (claimed)	87 hp (64.9 kW)
PTO (tested)	91.22 hp (68.0 kW)

Transmission

Clutch	wet disc / wet disc / wet disc
Description	Three synchronized gears (1-3) in three ranges (A-C) with power shuttle. Tractor must be stopped to shift ranges. / Four synchronized gears (1-4) in three ranges (A-C) with power shuttle. Tractor must be stopped to shift ranges. The 12-speed transmission became standard in 2014. / Four synchronized gears (1-4) in three ranges (A-C) with power shuttle and two-speed high/low shift. Tractor must be stopped to shift ranges. The high-low became an optiona transmission in 2014.
Gears	9 forward and reverse / 12 forward and reverse / 24 forward and 12 reverse
Transmission	Top Shaft Synchronized PowrReverser / 12-Speed PowrReverser / Hi-Lo PowrReverser
Type	partially synchronized / partially synchronized / partially synchronized
Transmission type	9-speed partially synchronized / 12-speed partially synchronized / 24-speed partially synchronized
Transmission type	9-speed partially synchronized / 12-speed partially synchronized / 24-speed partially synchronized

Mechanical

Cab	Two-post foldable ROPS. Cab optional with air-conditioning.
Description	Power steering / Hydraulic wet disc brakes
Differential lock	mechanical rear
Drive type	Two- or four-wheel drive
Final drives	inboard planetary

Hydraulics

Pressure	2828 psi (195.0 bar)
Pump flow	20 gpm (75.7 lpm)
SCV flow	20 gpm (75.7 lpm)
Type	open center
Valves	2 or 3

Hitch

Control	position control
Drawbar	Cat. II
Rear lift (at 24"/610mm)	5500 lbs (2494 kg)
Rear Type	II

PTO

Engine RPM	540@2085
Rear PTO	independent
Rear PTO Type	540/1000 (1.375)

Electrical

Battery volts	12
Ground	negative

Dimensions & Tires

2WD Clearance (front axle)	23.5 inches (59 cm)
2WD Length	168.5 inches (427 cm)
2WD Wheelbase	96.7 inches (245 cm)
4WD Clearance (front axle)	18 inches (45 cm)
4WD Length	166 inches (421 cm)
4WD Wheelbase	96.5 inches (245 cm)
Description	Flange rear axle
Front tread	60.4 to 80.4 inches (2WD) (153 to 204 cm) / 59.7 to 79.4 inches (4WD) (151 to 201 cm)
Height (cab)	108 inches (274 cm)
Height (exhaust)	110 inches (279 cm)
Width	96.5 inches*Width at rear axle flange. (245 cm)
2WD Rear tire	18.4-34
2WD Wheelbase	96.7 inches (245 cm)
4WD Wheelbase	96.5 inches (245 cm)
Front tire	10.00-16
Weight	7916 to 10000 pounds
2WD Standard tires (ag)	Front: 10.00-16. Rear: 18.4-34
4WD Standard tires (ag)	Front: 13.6-24. Rear: 18.4-34

John Deere 6105D Weight

2WD Cab Shipping	8200 lbs (3719 kg)
2WD ROPS Shipping	7916 lbs (3590 kg)
4WD Cab Operating	9760 lbs (4427 kg)
4WD Cab Shipping	10000 lbs (4536 kg)
4WD ROPS Shipping	9150 lbs (4150 kg)
Ballasted	14374 lbs (6520 kg)
Max capacity	17636 lbs (7999 kg)

John Deere 6105D attachments

Description	front-end loader

Nebraska Tractor Test 2055

Description	Diesel 9-speed 4WDMarch 29 - April 8, 2013Link: Nebraska Tractor Test 2055 file / PTO performance
Fuel use	5.3 gal/hour (20.1 l/hour)
Max power	91.22 hp (68.0 kW)

Speeds

Description	With 18.4-34 rear tires.

Nebraska Tractor Test Results

Test #2055

Download PDF

Test Date: March 29- April 8, 2013

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln, Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Max Power (1 Hour)

91.22 hp

@ N/A rpm

Rated Engine Speed

89.87 hp

N/A lb/hp·hr

Standard PTO Speed

90.28 hp

@ N/A rpm PTO

Torque Statistics

Maximum Torque	294 lb-ft (399 Nm)
Torque Rise	36.1%
At Engine RPM	1499 rpm

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM
Maximum Power (1 Hour)	91.22	68.02	1900

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
90.18	2199	5.73	0.45	15.75	N/A
78.80	2260	5.24	0.47	15.04	N/A
59.50	2278	4.38	0.52	13.60	N/A
40.10	2296	3.57	0.62	11.22	N/A
20.30	2300	2.56	0.88	7.94	N/A
2.70	2300	2.15	5.58	1.26	N/A

Category: II Quick Attach: No

Lift Capacity

Lift Cylinders 70mm

Max Force 5,722 lbs

Lift Cylinders 80mm

Max Force 7,304 lbs

Two Outlet Sets Combined

Sustained Pressure	2,672 psi
Flow Rate (min press)	21.20 gpm
Max Power	30.60 hp

Single Outlet Set

Sustained Pressure	2,608 psi
Flow Rate (min press)	20.90 gpm
Max Power	29.40 hp

Engine

Make	John Deere Diesel
Type	Four cylinder vertical with turbocharger and air to air aftercooler
Displacement	276 cu in (4525 ml)
Bore & Stroke	4.19" x 5.00" (106.5 mm x 127.0 mm)
Compression Ratio	19.0 to 1
Rated Engine Speed	2200 rpm
Air Cleaner	two paper elements
Exhaust	regenerative particulate filter integrated within an underhood muffler
Crankshaft	lengthwise

Chassis

Type	front wheel assist
Steering	hydrostatic
Transmission	selective gear fixed ratio
Speeds	9 forward (18.03 mph max)
Wheelbase	92.50 in (2450 mm)
Front Tread Width	60.0 (1523 mm) to 80.0 (2033 mm) in
Rear Tread Width	59.5 (1512 mm) to 79.2 (2012 mm) in
Brakes	wet disc operated by two foot pedals that can be locked together
Hydraulic Control	direct engine drive
Unladen Tractor Mass	9,760 lbs ( 4,427 kg )

Consumables

Fuel	No. 2 Diesel
DEF Fluid	N/A
Engine Oil	SAE 15W-40

Tires & Tracks

Rear Tires	18.4-34
Front Tires	13.6-24
Height of Drawbar	15.50 in (395 mm)

Static Weight

Rear	6,175 lbs
Front	3,760 lbs
Total	9,935 lbs
