John Deere 5120M Specs ( 2022-Present )

Name: John Deere 5120M
Brand: John Deere

Overview

The John Deere 5120M is a 120-horsepower utility tractor manufactured in Pune, India, starting in 2022. It features a 4.5L 4-cylinder diesel engine with Tier IV emissions compliance and is available in both ROPS and cab configurations with four-wheel drive.

Ideal Applications

Tested Performance Data: Nebraska Tractor Test results show a maximum pull of 10,257 lbs and a maximum drawbar power of 108.77 hp, exceeding the 3,197 lbs max drawbar rating.

Transmission and Hydraulic Configuration: This model offers PowrReverser, PowrQuad PLUS, or Powr8 transmissions with up to 32 forward speeds and an open center hydraulic system providing a 24.7 gpm pump flow.

Physical Dimensions and Lift Capacity: Equipped with a 92.5-inch wheelbase and 18.4R30 rear tires, the unit provides a rear lift capacity of 5,150 lbs and a front lift capacity of 4,257 lbs.

Production

Description	Utility tractor / Built in Pune, India / Original price was $85,264 in 2023
Manufacturer	John Deere

Engine

Cab Fuel tank	43.7 gal (165.4 L)
Engine type	John Deere 4.5L 4-cyl diesel
Exhaust fluid (DEF)	3.17 gal (12.0 L)
ROPS Fuel tank	37.7 gal (142.7 L)
Bore/Stroke	4.19x5.00 inches (106 x 127 mm)
Description	John Deere 4045 EWL / diesel / 4-cylinder / liquid-cooled
Displacement	276 ci (4.5 L)
Emissions	Tier IV
Maximum Power	123.5 hp (92.1 kW)
Power	120 hp (89.5 kW)
Rated RPM	2200
Starter	electric
Starter volts	12
Torque	369 lb-ft (500.4 Nm)
Torque RPM	1600
PTO (claimed)	105 hp (78.3 kW)

Transmission

Description	Four power shift gears in four ranges. / Eight power shift gears in three ranges. Four gears in reverse.
Gears	16 forward and reverse / 16 forward and reverse / 32 forward and 16 reverse
Transmission	PowrReverser / PowrQuad PLUS / Powr8
Type	4-speed power shift / 8-speed power shift
Transmission type	16-speed / 16-speed 4-speed power shift / 32-speed 8-speed power shift
Transmission type	16-speed / 16-speed 4-speed power shift / 32-speed 8-speed power shift

Mechanical

Cab	Two-post folding ROPS. Cab optional with air-conditioning
Description	Power steering
Differential lock	electro-hydraulic rear
Drive type	Four-wheel drive

Hydraulics

Mid valves	2 or 3
Pump flow	24.7 gpm (PowReverser) (93.5 lpm)
Rear valves	2 or 3
SCV flow	18.4 gpm (PowReverser) (69.6 lpm)
Type	open center

Hitch

Control	position control and lower-link draft sensing
Front Hitch	II/I
Front lift	4257 lbs (1930 kg)
Rear lift	5150 lbs (PowrReverser) (2336 kg)
Rear Type	II/I

PTO

Clutch	electro-hydraulic
Engine RPM	540@2100
Rear PTO	independent
Rear PTO Type	540 (1.375)

Electrical

Battery volts	12
Cab Charging amps	120
Charging system	alternator
Ground	negative
ROPS Charging amps	90

Dimensions & Tires

Cab Length	161 inches (408 cm)
Front tread	51.1 to 78.6 inches (129 to 199 cm)
Rear tread	53.1 to 90 inches (134 to 228 cm)
ROPS Length	160 inches (406 cm)
Wheelbase	92.5 inches (234 cm)
Front tire	12.4R24
Rear tire	18.4R30
Weight	8765 to 9185 pounds
Wheelbase	92.5 inches (234 cm)
Standard tires (ag)	Front: 12.4R24. Rear: 18.4R30

John Deere 5120M Weight

Cab Shipping	9185 lbs (4166 kg)
Max Drawbar	3197 lbs (1450 kg)
ROPS Shipping	8765 lbs (3975 kg)

References

Description	5M Tractors published in 2022, by John Deere

Nebraska Tractor Test Results

Test #2272

Download PDF

Test Date: November 6 - 9, 2023

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Max Power (1 Hour)

114.72 hp

@ 1901 rpm

Rated Engine Speed

106.51 hp

N/A lb/hp·hr

Standard PTO Speed

111.96 hp

@ N/A rpm PTO

Torque Statistics

Maximum Torque	346 lb-ft (469 Nm)
Torque Rise	36.1%
At Engine RPM	1602 rpm

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM
Maximum Power (1 Hour)	114.72	85.54	1901

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
106.51	2201	6.46	0.43	16.49	0.37
92.58	2253	5.93	0.45	15.60	0.30
70.36	2282	4.99	0.50	14.09	0.25
48.37	2299	4.07	0.59	11.90	0.18
23.62	2300	2.88	0.86	8.20	0.14
0.33	2300	1.92	41.53	0.17	0.07

Fuel Consumption Characteristics

Click column headers to sort

Condition	Power	Pull (lbs)	Speed	Slip	DEF lb/hp	Air °F	Cool °F
Power at Rated Engine Speed—8th(B4) Gear	100.53	6,420	5.87	3.40	0.04	60	202
75% of Pull at Rated Engine Speed—8th(B4...	78.84	4,830	6.12	2.30	0.04	68	199
50% of Pull at Rated Engine Speed—8th(B4...	53.70	3,219	6.26	1.30	0.04	68	199
75% of Pull at Reduced Engine Speed—10th...	78.45	4,812	6.11	2.30	0.04	67	196
50% of Pull at Reduced Engine Speed—10th...	53.63	3,222	6.24	1.40	0.04	67	193

Unballasted Front Drive Engaged 2200 Engine RPM Maximum Power In Selected Gears

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	hp·hr/gal	Air °F	Cool °F	Barometer Inch Hg	Def Consumption Lb Hp Hr	Fuel Lb Hp Hr
5th(B1)	78.89	10,257	2.89	2252	13.20	13.10	54	199	28.53	0.04	0.54
6th(B2)	94.65	9,648	3.68	2201	8.20	14.45	56	201	28.53	0.04	0.49
7th(B3)	99.70	7,928	4.72	2200	4.80	15.12	59	201	28.55	0.04	0.47
8th(B4)	100.53	6,420	5.87	2200	3.40	15.36	60	202	28.56	0.04	0.46
9th(C1)	101.67	6,289	6.06	2200	3.30	15.54	62	202	28.58	0.03	0.45
10th(C2)	101.77	5,054	7.55	2200	2.40	15.62	61	202	28.58	0.03	0.45
11th(C3)	101.29	4,038	9.41	2200	1.80	15.57	63	203	28.59	0.04	0.45

Unballasted Front Drive Engaged 1900 Engine RPM Maximum Power In Selected Gears

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	hp·hr/gal	Air °F	Cool °F	Barometer Inch Hg	Def Consumption Lb Hp Hr	Fuel Lb Hp Hr
5th(B1)	77.93	10,215	2.87	2251	13.90	12.90	55	200	28.53	0.04	0.55
6th(B2)	94.48	9,827	3.61	2178	9.20	14.48	56	202	28.53	0.04	0.49
7th(B3)	103.23	9,001	4.31	2038	6.30	15.80	59	201	28.55	0.04	0.45
8th(B4)	105.32	7,906	5.00	1900	4.90	16.62	61	202	28.57	0.04	0.42
9th(C1)	106.36	7,716	5.17	1900	4.70	16.70	62	201	28.58	0.04	0.42
10th(C2)	108.36	6,284	6.47	1900	3.30	17.05	62	201	28.59	0.04	0.41
11th(C3)	108.77	5,052	8.08	1900	2.50	17.16	63	203	28.58	0.04	0.41

Category: 2 Quick Attach: None

Two Outlet Sets Combined

Sustained Pressure	2,835 psi
Delivery Pressure	2,359 psi
Flow Rate (min press)	N/A gpm
Max Power	28.90 hp

Single Outlet Set

Sustained Pressure	2,835 psi
Delivery Pressure	2,343 psi
Flow Rate (min press)	N/A gpm
Max Power	28.80 hp

Engine

Make	John Deere Diesel
Type	four cylinder vertical with turbocharger, air to air intercooler and D.E.F. (diesel exhaust fluid) exhaust treatment
Displacement	276 cu in (4525 ml)
Compression Ratio	16.9 to 1
Rated Engine Speed	2200 rpm
Air Cleaner	two paper elements and aspirator
Exhaust	regenerative aftertreatment system consisting of DOC (diesel oxidation catalyst) and SCR (selective catalyst reduction) with a vertical exhaust
Crankshaft	lengthwise

Chassis

Type	front wheel assist
Steering	hydrostatic
Transmission	selective gear fixed ratio with partial (4) range operator controlled powershift
Speeds	16 forward (24.86 mph max)
Wheelbase	92.50 in (2350 mm)
Front Tread Width	55.0 to 78.7 in
Rear Tread Width	58.9 to 70.7 in
Brakes	wet disc hydraulically actuated by two foot pedals which can be locked together
Hydraulic Control	direct engine drive
Unladen Tractor Mass	9,910 lbs ( 4,495 kg )

Consumables

Fuel	No. 2 Diesel
DEF Fluid	32% aqueous urea solution

Tires & Tracks

Rear Tires	Two 460/85R34; **; 12 psi (85 kPa)
Front Tires	Two 340/85R24; **; 12 psi (85 kPa)
Height of Drawbar	20.5 in (520 mm)

Static Weight

Rear	6,300 lbs
Front	3,785 lbs
Total	10,085 lbs
