John Deere 5100R Specs ( 2009-2025 )
Overview
The John Deere 5100R is a utility farm tractor produced between 2009 and 2025 in Mannheim, Germany, featuring a 4.5L four-cylinder turbocharged diesel engine. It is equipped with a four-wheel drive mechanical system and offers transmission options including 16-speed or 32-speed PowrQuad and AutoQuad Plus configurations. Tested performance data indicates a maximum power output of 103.73 hp and a rear lift capacity of up to 7,158 lbs at the hitch ends.
Ideal Applications
Hydraulic System Performance:
The tractor is available with either an open center system providing 25.5 gpm total flow or a pressure-flow compensated system rated at 39 gpm total flow.
Nebraska PTO Testing Results:
During Nebraska Tractor Test 2194, the 5100R demonstrated a maximum power of 103.73 hp and a power at rated PTO speed of 97.92 hp.
Rear Hitch and Lift Specifications:
Equipped with a Type II/I rear hitch and electro-hydraulic draft sensing, the unit provides a rated lift capacity of 6,979 lbs at 24 inches behind the points.
Production
| Description | Utility tractor / Built in Mannheim, Baden-Württemberg, Germany |
|---|---|
| Manufacturer | John Deere |
Engine
| Engine type | John Deere 4.5L 4-cyl diesel |
|---|---|
| Fuel tank | 34.3 gal (129.8 L) |
| Bore/Stroke | 4.19x5.00 inches (106 x 127 mm) |
| Coolant capacity | 29.6 qts (28.0 L) |
| Coolant change | 1500 h |
| Description | John Deere 4045HL284 / turbocharged diesel / 4-cylinder 8-valve / liquid-cooled |
| Displacement | 276 ci (4.5 L) |
| Emissions | Tier III/Stage IIIa |
| Firing order | 1-3-4-2 |
| Fuel system | high-pressure common rail |
| Oil capacity | 20.6 qts (19.5 L) |
| Oil change | 500 h |
| Power | 100 hp (74.6 kW) |
| Rated RPM | 2300 |
| Starter | electric |
| Starter volts | 12 |
| Open center PTO (claimed) | 85 hp (63.4 kW) |
| PFC PTO (claimed) | 90 hp (67.1 kW) |
| PTO (claimed) | 87 hp (64.9 kW) |
| PTO (tested) | 103.73 hp (77.4 kW) |
Transmission
| Clutch | electro-hydraulic wet disc / electro-hydraulic wet disc / electro-hydraulic wet disc / electro-hydraulic wet disc |
|---|---|
| Description | Four power shift gears (1-4) in four synchronized ranges (A-D) with electric de-clutch button and reverser lever. / Four power shift gears (1-4) in four synchronized ranges (A-D) with electric de-clutch button and reverser lever. Programmable automatic gear shifting. |
| Gears | 16 forward and reverse / 16 forward and reverse / 32 forward and reverse / 32 forward and reverse |
| Transmission | PowrQuad Plus / AutoQuad Plus / PowerQuad Plus with underdrive / AutoQuad Plus with underdrive |
| Type | four-speed power shuft / four-speed power shuft / creeper / creeper |
| Transmission type | 16-speed four-speed power shuft / 32-speed creeper |
| Transmission type | 16-speed four-speed power shuft / 32-speed creeper |
Mechanical
| Cab | Cab standard. Optional air-conditioning. |
|---|---|
| Description | Power steering / Wet disc brakes |
| Differential lock | electro-hydraulic |
| Drive type | Four-wheel drive |
| Final drives | inboard planetary |
Capacity
| Exhaust fluid (DEF) | 2.9 gal (11.0 L) |
|---|---|
| Fuel | 38 gal (143.8 L) |
| Open center Hydraulic system | 11.75 gal (44.5 L) |
| PFC Hydraulic system | 12.5 gal (47.3 L) |
Hydraulics
| Open center Capacity | 11.75 gal (44.5 L) |
|---|---|
| Open center SCV flow | 19.3 gpm (73.1 lpm) |
| Open center Steering flow | 6.2 gpm (23.5 lpm) |
| Open center Total flow | 25.5 gpm (96.5 lpm) |
| Open center Type | open center |
| PFC Capacity | 12.5 gal (47.3 L) |
| PFC SCV flow | 26.4 gpm (99.9 lpm) |
| PFC Steering flow | 8.1 gpm (30.7 lpm) |
| PFC Total flow | 39 gpm (147.6 lpm) |
| PFC Type | pressure-flow compensated |
| Pressure | 2900 psi (200.0 bar) |
| Total flow | 14.8 gpm (56.0 lpm) |
| Type | load sensing pressure compensated |
| Valves | up to 3 |
Hitch
| Control | electro-hydraulic draft sensing |
|---|---|
| Rear lift (at 24"/610mm) | 6979 lbs (3165 kg) |
| Rear lift (at ends) | 7158 lbs (3246 kg) |
| Rear Type | II/I |
PTO
| Clutch | electro-hydraulic wet disc |
|---|---|
| Engine RPM | 540@2097 |
| Front PTO Type | 1000 |
| Rear PTO | independent |
| Rear PTO Type | 540/540E |
Electrical
| Battery CCA | 950 |
|---|---|
| Battery volts | 12 |
| Charging amps | 200 |
| Charging system | alternator |
| Ground | negative |
Dimensions & Tires
| Ground clearance | 13.4 inches (34 cm) |
|---|---|
| Height (cab) | 102.2 inches (259 cm) |
| Length | 155.5 inches (394 cm) |
| Max weight | 14,550 lbs (6599 kg) |
| Shipping weight | 8,157 lbs (3700 kg) |
| Wheelbase | 88.6 inches (225 cm) |
| Width | 85.6 inches (217 cm) |
| Front tire | 13.6R24 |
| Rear tire | 16.9R34 |
| Weight | 8,157 lbs (3700 kg) |
| Wheelbase | 88.6 inches (225 cm) |
| Ag front | 13.6R24 |
| Ag rear | 16.9R34 |
| Industrial front | 12.5/80-18 |
| Industrial rear | 19.5L-24 |
| Lawn/turf front | 44x18-20 |
| Lawn/turf rear | 23.1-26 |
| Optional tires (ag) | Front: 11.2R28. Rear: 13.6R38 |
| Standard tires (ag) | Front: 12.4R24. Rear: 18.4R30 |
5100R Serial Numbers
| Location: | Right side of tractor frame, above the front axle. |
|---|
John Deere 5100R attachments
| Description | front-end loader |
|---|
Nebraska Tractor Test 2193
| Description | Diesel CommandQuad 4WD Open CenterApril 18 - 24, 2018Link: Nebraska Tractor Test 2193 file / PTO performance |
|---|---|
| Fuel use | 5.3 gal/hour (20.1 l/hour) / 5.3 gal/hour (20.1 l/hour) / 5.4 gal/hour (20.4 l/hour) |
| Max power | 100.11 hp (74.7 kW) |
| Power at rated engine speed | 88.17 hp (65.7 kW) |
| Power at rated PTO speed | 94.51 hp (70.5 kW) |
Nebraska Tractor Test 2194
| Description | Diesel CommandQuad 4WD PFCApril 16 - 24, 2018Link: Nebraska Tractor Test 2194 file / PTO performance |
|---|---|
| Fuel use | 5.6 gal/hour (21.2 l/hour) / 5.5 gal/hour (20.8 l/hour) / 5.5 gal/hour (20.8 l/hour) |
| Max power | 103.73 hp (77.4 kW) |
| Power at rated engine speed | 92.95 hp (69.3 kW) |
| Power at rated PTO speed | 97.92 hp (73.0 kW) |
References
| Description | 5 Series published in 2009, by John Deere / 5 Series Speciality tractors published in 2009, by John Deere |
|---|
Speeds
| Description | With 420/85R30 rear tires. Reverse speeds are 5% faster than forward speeds. / With 420/85R30 rear tires. Reverse speeds are 5% faster than forward speeds. / With 420/85R30 rear tires. Reverse speeds are 5% faster than forward speeds. / With 420/85R30 rear tires. Reverse speeds are 5% faster than forward speeds. |
|---|
Tractor Tests
| Description | NTTL 2193: diesel CommandQuad 4WD Open Center / NTTL 2194: diesel CommandQuad 4WD PFC |
|---|
Nebraska Tractor Test Results
Test #2193
Test Date:
April 18 - 24, 2018
Location:
Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln Nebraska 68583-0832
This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.
Maximum Power & Fuel Consumption
Max Power (1 Hour)
100.11 hp
@ 1851 rpm
Rated Engine Speed
88.17 hp
N/A lb/hp·hr
Standard PTO Speed
94.51 hp
@ N/A rpm PTO
Torque Statistics
| Maximum Torque | 302 lb.-ft. (410 Nm) at 1401 rpm |
|---|---|
| Torque Rise | 43.6% |
PTO Power Curve
Maximum Power & Fuel Consumption Details
| Condition | HP | kW | RPM | PTO RPM |
|---|---|---|---|---|
| Rated Engine Speed | 88.17 | 65.75 | 2201 | 566 |
| Maximum Power (1 Hour) | 100.11 | 74.66 | 1851 |
Varying Power & Fuel Consumption
Click column headers to sort
| Power | RPM | gal/hr | lb/hp·hr | hp·hr/gal | DEF gal/hr |
|---|---|---|---|---|---|
| 88.17 | 2201 | 5.31 | 0.42 | 16.59 | 0.23 |
| 77.10 | 2266 | 4.89 | 0.45 | 15.76 | 0.20 |
| 58.20 | 2281 | 4.10 | 0.50 | 14.19 | 0.14 |
| 39.12 | 2293 | 3.32 | 0.60 | 11.80 | 0.07 |
| 19.74 | 2310 | 2.46 | 0.88 | 8.01 | 0.05 |
| 0.72 | 2324 | 1.84 | 18.00 | 0.39 | 0.02 |
