Fendt 1151 Vario MT Specs ( 2020-1100 )

Name: Fendt 1151 Vario MT
Brand: Fendt

Overview

The Fendt 1151 Vario MT is a high-horsepower agricultural crawler tractor featuring a 504.2 hp MAN 15.3L 6-cylinder diesel engine and a VarioDrive continuously-variable transmission. Designed for heavy-duty farm applications, it offers a robust 42,000 lb operating weight and an adjustable gauge width ranging from 88 to 128 inches.

Ideal Applications

Heavy Tillage and Field Work: Utilizing its 504.2 hp engine and 1,844 lb-ft of torque, this crawler tractor is built to handle demanding implements while maintaining traction through its track-driven mechanical system.

High-Capacity Hydraulic Operations: With a closed center pressure-flow compensated hydraulic system providing 58.1 gpm pump flow and up to 8 rear valves, this model is well-suited for operating complex hydraulic machinery.

Precision Field Applications: The VarioDrive CVT provides infinite forward and reverse gears, allowing operators to maintain precise speeds for specific agricultural tasks while working within a standard air-conditioned cab.

Production

Description	Agricultural Crawler tractor
Manufacturer	Fendt (a part of AGCO)

Engine

Engine type	MAN 15.3L 6-cyl diesel
Exhaust fluid (DEF)	35.7 gal (135.1 L)
Fuel tank	350 gal (1324.8 L)
Bore/Stroke	5.43x6.69 inches (138 x 170 mm)
Description	MAN D3876 / turbocharged diesel / 6-cylinder / liquid-cooled inline
Displacement	933.7 ci (15.3 L)
Emissions	Tier IV
Oil change	500 h
Rated Power (gross)	504.2 hp (376.0 kW)
Rated RPM	1730
Starter	electric
Starter volts	24
Torque	1844 lb-ft (2500.5 Nm)
Torque RPM	1450
Engine (gross)	504.2 hp (376.0 kW)

Transmission

Description	continuously-variable transmission
Gears	infinite forward and reverse
Transmission	VarioDrive CVT
Type	continuously-variable transmission

Mechanical

Cab	Cab standard with air-conditioning.
Drive	crawler

Hydraulics

Pressure	2900 psi (200.0 bar)
Pump flow	58.1 gpm (219.9 lpm)
Rear valves	4 to 8
Type	closed center pressure-flow compensated

PTO

Rear PTO	independent
Rear PTO Type	1000/1000E

Electrical

Batteries	3
Battery volts	12
Charging amps	325
Charging system	alternator
Ground	negative

Dimensions & Tires

Gauge	88 to 128 inches (223 to 325 cm)
Ground clearance	14.1 inches (35 cm)
Height	148 inches (375 cm)
Length	266 inches (675 cm)
Max weight	59000 lbs (26762 kg)
Weight	42000 lbs (19051 kg)
Wheelbase	118 inches (299 cm)
Width	116.1 inches*Minimum width (294 cm)

Dimensions & Tracks

Description	Tracks
Weight	42000 lbs (19051 kg)
Wheelbase	118 inches (299 cm)

References

Description	Fednt 1100 Vario MT Series published in 2020, by Fendt / Fednt 1100 Vario MT published in 2020, by Fendt

Variants

MT851	similar Challenger model

Nebraska Tractor Test Results

Test #2244

Download PDF

Test Date: October 20 - 28, 2021

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln, Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Max Power (1 Hour)

484.60 hp

@ 1501 rpm

Rated Engine Speed

477.67 hp

N/A lb/hp·hr

Standard PTO Speed

480.95 hp

@ N/A rpm PTO

Torque Statistics

Maximum Torque	1,788 lb-ft (2,424 Nm)
Torque Rise	23.3%

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM	PTO RPM	Fuel gal/hr	Fuel L/hr	DEF gal/hr	DEF L/hr
Rated Engine Speed	477.67	356.20	1730	1379	23.67	89.60	1.63	6.17
Maximum Power (1 Hour)	484.60	361.37	1501		22.97	86.94	1.96	7.41

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
477.67	1730	23.67	0.35	20.18	1.63
408.93	1743	20.75	0.35	19.71	1.13
308.49	1753	16.31	0.37	18.91	1.03
207.22	1762	12.12	0.41	17.10	1.08
104.03	1771	8.05	0.54	12.92	0.82
2.34	1780	4.66	13.88	0.50	0.05

Manual Mode 1730 Engine RPM (Unballasted)

Click column headers to sort

Setting	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr
3.10	324.57	44,662	2.73	1741	13.20	0.03	45	198	28.82	15.01	0.47
3.70	378.73	41,007	3.47	1729	8.10	0.03	48	197	28.82	16.14	0.43
4.30	392.60	35,233	4.18	1731	4.60	0.03	51	197	28.80	16.70	0.42
4.70	397.52	32,921	4.53	1730	3.60	0.03	42	198	28.95	16.84	0.42
5.00	398.31	30,728	4.86	1730	3.00	0.03	42	198	28.95	16.88	0.41
5.60	398.08	27,414	5.45	1730	2.30	0.04	41	199	28.92	16.87	0.41
6.20	400.37	24,431	6.15	1730	1.70	0.04	41	199	28.92	16.97	0.41
6.80	402.97	22,259	6.79	1730	1.30	0.04	43	199	28.95	17.11	0.41
7.50	402.10	20,283	7.43	1730	0.90	0.04	43	199	28.95	17.04	0.41
8.10	399.13	18,538	8.08	1730	0.80	0.04	43	198	28.96	16.92	0.41

Ballasted At 1500 Engine RPM

Click column headers to sort

Setting	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr
2.50	366.92	62,213	2.22	1602	11.40	0.04	50	199	28.51	15.63	0.45
3.10	392.77	54,154	2.72	1578	6.70	0.04	50	199	28.52	16.94	0.41
3.70	408.27	43,385	3.53	1544	3.50	0.04	50	197	28.53	17.70	0.39
4.30	411.12	40,312	3.83	1520	2.70	0.05	49	198	28.53	17.92	0.39
4.70	412.34	35,204	4.40	1508	2.00	0.05	49	197	28.53	18.00	0.39
5.00	410.23	32,103	4.79	1500	1.70	0.05	50	197	28.54	17.97	0.39
5.60	408.42	28,410	5.39	1500	1.50	0.05	50	197	28.55	17.90	0.39
6.20	408.27	25,068	6.11	1499	1.10	0.05	50	196	28.55	17.86	0.39
6.80	407.60	22,688	6.74	1499	0.90	0.05	50	196	28.55	17.85	0.39
7.50	404.25	20,495	7.40	1502	0.80	0.05	50	196	28.55	17.70	0.40
8.10	400.12	18,589	8.07	1504	0.70	0.05	50	197	28.55	17.56	0.40

Manual Mode 1500 Engine RPM (Unballasted)

Click column headers to sort

Setting	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr
3.10	322.35	44,248	2.73	1741	12.90	0.03	45	198	28.82	15.07	0.46
3.70	381.47	41,861	3.42	1628	9.00	0.04	48	196	28.81	16.37	0.43
4.30	398.06	36,966	4.04	1535	5.10	0.05	52	196	28.80	17.28	0.40
4.70	400.67	33,276	4.52	1510	3.90	0.05	56	195	28.78	17.46	0.40
5.00	401.81	30,930	4.88	1501	3.10	0.05	55	196	28.78	17.64	0.40
5.60	404.32	27,471	5.52	1503	2.20	0.05	56	196	28.77	17.69	0.40
6.20	405.53	24,605	6.18	1501	1.70	0.06	41	196	28.93	17.73	0.39
6.80	405.23	22,219	6.84	1500	1.20	0.06	44	197	28.96	17.69	0.40
7.50	405.01	20,394	7.45	1500	0.90	0.06	44	197	28.96	17.69	0.40
8.10	400.50	18,521	8.11	1502	0.80	0.06	45	198	28.96	17.54	0.40

Fuel Consumption Characteristics (Unballasted)

Click column headers to sort

Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Air °F	Cool °F	Barometer Inch Hg	Condition	Fuel Hp Hr Gal	Fuel Lb Hp Hr
398.08	27,414	5.45	1730	2.30	0.04	41	199	28.92	Power at Rated Engine Speed—5.6 mph(9.0 km/h)	16.87	0.41
306.88	20,602	5.59	1747	1.00	0.03	48	199	28.96	75% of Pull at Rated Engine Speed—5.6 mph(9.0km/h)	16.28	0.43
205.69	13,736	5.62	1757	0.50	0.04	49	201	28.96	50% of Pull at Rated Engine Speed—5.6 mph(9.0km/h)	14.68	0.48
306.32	20,550	5.59	1216	1.10	0.08	50	195	28.96	75% of Pull at Reduced Engine Speed—5.6 mph(9.0km/h)	18.05	0.39
205.98	13,773	5.61	1170	0.50	0.04	50	196	28.95	50% of Pull at Reduced Engine Speed—5.6 mph(9.0km/h)	16.96	0.41

Category: 4N Quick Attach: yes

Lift Capacity

Three Outlet Sets Combined

Sustained Pressure	N/A psi
Flow Rate (min press)	N/A gpm
Max Power	N/A hp

Single Outlet Set

Sustained Pressure	N/A psi
Flow Rate (min press)	N/A gpm
Max Power	N/A hp

Engine

Make	MAN Diesel
Type	six cylinder vertical with turbocharger, air to air intercooler and D.E.F. (diesel exhaust fluid) technology
Displacement	930 cu in (15256 ml)
Compression Ratio	18.0 to 1
Rated Engine Speed	1730 rpm
Air Cleaner	two paper elements and aspirator
Exhaust	DOC (diesel oxidation catalyst) and SCR (selective catalyst reduction) with a vertical muffler
Crankshaft	lengthwise

Chassis

Type	Tracklayer-rubber tracked
Steering	electro-hydraulic differential steering controlled by steering wheel
Transmission	CVT. Infinitely variable hydrostatic using variable displacement pump and motors
Brakes	wet multiple disc hydraulically actuated by foot pedal
Hydraulic Control	direct engine drive
Unladen Tractor Mass	42,425 lbs ( 19,244 kg )

Consumables

Fuel	No. 2 Diesel
DEF Fluid	32% aqueous urea solution

Sound Levels

Bystander	85.80 dB(A)
At No Load At 4 6 Mph 7 5 Km H Engine Speed 1040 RPM	61.10 dB(A)
At No Load At 4 6 Mph 7 5 Km H Engine Speed 1770 RPM	66.60 dB(A)

Tires & Tracks

Height of Drawbar	21.5 in (545 mm), 21.0 in (535 mm)

Static Weight

Rear	N/A lbs
Front	N/A lbs
Total	N/A lbs
