Challenger MT575D Specs ( 2012-2014 )

Name: Challenger MT575D
Brand: Challenger

Overview

The Challenger MT575D is a row-crop farm tractor produced from 2012 to 2014 at the Beauvais, France factory. It features an AGCO Power six-cylinder diesel engine with selective catalytic reduction and was offered with either the 24-speed AutoPower VI power shift or the TechStar CVT transmission. Tested performance data lists a maximum PTO output of 202.14 hp and a shipping weight of 17,000 lbs.

Ideal Applications

Tested Power and Pulling Performance: The Nebraska Tractor Test reported a maximum PTO power of 202.14 hp, a maximum drawbar power of 188.27 hp, and a maximum pull of 16,822 lbs.

Transmission and Hitch Configuration: This model is equipped with either a 24-speed power shift or an infinite forward and reverse CVT, complemented by a Category III rear hitch with 12,500 lbs of lift capacity.

Fluid and Mechanical Specifications: The tractor is built with a 114-gallon fuel tank, an 11-gallon DEF capacity, and a closed center load sensing hydraulic system delivering 29 gpm of total flow.

Production

Description	Row-Crop tractor
Factories	Beauvais, France
Manufacturer	Challenger (a part of AGCO)
Original price	$161,244 (2013 classic )

Engine

Engine type	AGCO Power 6.6L 6-cyl diesel / AGCO Power 7.4L 6-cyl diesel
Air cleaner	dual stage dry / dual stage dry
Bore/Stroke	4.252x4.724 inches (108 x 120 mm) / 4.252x5.276 inches (108 x 134 mm)
Compression	17.4:1 / 17.8:1
Description	AGCO Power / turbocharged intercooled diesel / 6-cylinder / liquid-cooled / AGCO Power / turbocharged intercooled diesel / 6-cylinder / liquid-cooled
Displacement	402.5 ci (6.6 L) / 449.4 ci (7.4 L)
Emission control	selective catalyitic reduction (SCR) / selective catalyitic reduction (SCR)
Emissions	Interim Tier IV / Interim Tier IV
Fuel system	electronic high pressure common rail / electronic high pressure common rail
Maximum Power	215 hp (160.3 kW) / 215 hp (160.3 kW)
Power	200 hp (149.1 kW) / 200 hp (149.1 kW)
Pre-heating	thermostart / thermostart
Rated RPM	2100 / 2100
Starter	electric / electric
Starter volts	12 / 12
Engine type	AGCO Power 6.6L 6-cyl diesel / AGCO Power 7.4L 6-cyl diesel
Drawbar (tested)	168.77 hp (125.9 kW)
PTO (claimed)	165 hp (123.0 kW)
PTO (tested)	202.4 hp (150.9 kW)

Transmission

Gears	24 forward and reverse / infinite forward and reverse
Transmission	AutoPower VI / TechStar CVT
Type	six-speed power shift / continuously variable transmission
Description	continuously variable transmission
Transmission type	24-speed six-speed power shift
Description	continuously variable transmission
Transmission type	24-speed six-speed power shift

Mechanical

Cab	Cab standard with air-conditioning. AGCO System 150 (optional); AGCOMMAND (optional)
Description	Hydraulic wet disc brakes
Differential lock	electro-hydraulic full locking
Drive type	Four-wheel drive
Final drives	inboard planetary
Steering	hydrostatic power
Trailer brakes	hydraulic (optional)

Capacity

Exhaust fluid (DEF)	11 gal (41.6 L)
Fuel	114 gal (431.5 L)
Hydraulic system	26.4 gal (99.9 L)

Hydraulics

Capacity	26.4 gal (99.9 L)
Pressure	2900 psi (200.0 bar)
SCV flow	24.3 gpm (92.0 lpm)
Total flow	29 gpm (109.8 lpm)
Type	closed center load sensing (CCLS)
Valves	2 to 4

Hitch

Control	electronic lower link draft control
Drawbar	Cat. 2
Rear lift (at 24"/610mm)	12500 lbs (AutoPower) (5670 kg)
Rear Type	III

PTO

Clutch	electro-hydraulic
Rear PTO	independent
Rear PTO Type	540/1000

Electrical

Batteries	2
Battery CCA	600
Battery volts	12
Charging amps	175
Charging system	alternator
Ground	negative

Dimensions & Tires

Standard tires (ag)	Front: 420/85R28. Rear: 480/80R42
Bar rear axle	3.23 by 80 inches (82 by 2032 mm) / 3.74 by 89.6 inches (CVT) (94 by 2275 mm)
Description	Flange rear axle
Height (cab)	120.8 inches (306 cm)
Length	200.2 inches (508 cm)
Long bar rear axle	3.23 by 105 inches (82 by 2667 mm) / 3.74 by 113 inches (CVT) (94 by 2870 mm)
Max weight	27560 lbs (12501 kg)
Shipping weight	17000 lbs (7711 kg)
Wheelbase	117.8 inches (299 cm)
Front tire	420/85R28
Rear tire	480/80R42
Weight	17000 lbs (7711 kg)
Wheelbase	117.8 inches (299 cm)

OCED Tractor Test 2104A

Description	Diesel AutoPower VI 4WDNovember 18 - December 3, 2014Link: OCED Tractor Test 2104A file / PTO performance / Drawbar performance / Gear 3A used for power test. / Gear 2B used for pull test.
Fuel use	11.3 gal/hour (42.8 l/hour) / 11.2 gal/hour (42.4 l/hour) / 11.2 gal/hour (42.4 l/hour) / 11.1 gal/hour (42.0 l/hour)
Max power	202.14 hp (150.7 kW) / 168.77 hp (125.9 kW)
Max pull	16822 lbs (7630 kg)
Power at rated engine speed	185.13 hp (138.1 kW)
Power at rated PTO speed	196.82 hp (146.8 kW)

OCED Tractor Test 2705

Description	6.6L diesel Techstar CVT 4WDJanuary 2012 - March 2012, Link: OCED Tractor Test 2705 file / PTO performance / Drawbar performance / Pull at 8.62 KPH / Pull at 4.00 KPH
Fuel use	10.8 gal/hour (40.9 l/hour) / 10.2 gal/hour (38.6 l/hour) / 10.5 gal/hour (39.7 l/hour) / 9.6 gal/hour (36.3 l/hour)
Max power	202.4 hp (150.9 kW) / 135.2 hp (100.8 kW)
Max pull	17040 lbs (7729 kg)
Power at rated engine speed	176.7 hp (131.8 kW)
Power at rated PTO speed	187.5 hp (139.8 kW)

References

Description	Challenger MT500D Series published in 2011, by AGCO / Challenger MT500D Series published in 2013, by AGCO

Tractor Tests

Description	OECD 2705: 6.6L diesel Techstar CVT 4WD / OECD 2104A: diesel AutoPower VI 4WD

Variants

7622	similar Massey Ferguson model

Nebraska Tractor Test Results

Test #2104A

Download PDF

Test Date: November 18 to December 3, 2014

Location: Nebraska Tractor Test Laboratory, University of Nebraska, Lincoln, Nebraska 68583-0832

This section is compiled from original Nebraska Tractor Test PDFs using AI-assisted extraction and human review. For full verification, download the source PDF above. Differences between reports, incomplete source data, and occasional extraction or data entry mistakes can occur.

PTO Drawbar Hydraulics Technical Sound Tires & Weight

Maximum Power & Fuel Consumption

Max Power (1 Hour)

202.14 hp

@ 1950 rpm

Rated Engine Speed

185.13 hp

N/A lb/hp·hr

Standard PTO Speed

196.82 hp

@ N/A rpm PTO

Torque Statistics

Maximum Torque	644 lb-ft (873 Nm)
Torque Rise	39.6%
At Engine RPM	1500 rpm

PTO Power Curve

Maximum Power & Fuel Consumption Details

Condition	HP	kW	RPM	Fuel gal/hr	Fuel L/hr	DEF gal/hr	DEF L/hr
Rated Engine Speed	185.13	138.05	2100	11.15	42.22	0.59	2.24
Standard PTO Speed (1000 rpm)	196.82	146.77	2000	11.24	42.54	0.66	2.51
Maximum Power (1 Hour)	202.14	150.74	1950	11.28	42.71	0.71	2.69

Varying Power & Fuel Consumption

Click column headers to sort

Power	RPM	gal/hr	lb/hp·hr	hp·hr/gal	DEF gal/hr
185.13	2100	11.15	0.42	N/A	0.59
159.01	2123	9.69	0.43	N/A	0.54
119.76	2131	7.69	0.45	N/A	0.49
80.07	2139	5.87	0.52	N/A	0.39
40.21	2148	3.95	0.69	N/A	0.33
2.66	2155	2.32	6.13	N/A	0.24

Drawbar Performance At 2100 RPM (Unballasted) Front Drive Engaged

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr	Temp Air F	Temp Cooling F
8th(2B)	127.63	16,822	2.85	2121	14.40	0.03	28.72	13.60	0.52	46	188
9th(2C)	148.05	16,105	3.45	2114	10.00	0.03	28.72	14.43	0.49	45	190
10th(2D)	157.49	13,819	4.27	2099	6.60	0.03	28.73	15.17	0.46	43	190
11th(3A)	168.77	12,963	4.88	2100	5.30	0.03	28.69	15.21	0.46	46	193
12th(2E)	167.30	12,235	5.13	2100	4.60	0.03	28.69	15.05	0.47	46	194
13th(3B)	170.52	10,681	5.99	2100	3.70	0.03	28.70	15.34	0.46	47	194
14th(2F)	169.97	10,201	6.25	2100	3.50	0.03	28.70	15.35	0.46	47	195
15th(3C)	172.43	9,139	7.08	2100	2.70	0.03	28.71	15.54	0.45	47	193
16th(3D)	172.76	7,543	8.59	2100	1.80	0.03	28.71	15.62	0.45	47	193

Drawbar Performance At 1950 RPM (Unballasted) Front Drive Engaged

Click column headers to sort

Gear	Power	Pull (lbs)	Speed	RPM	Slip	DEF lb/hp	Barometer Inch Hg	Fuel Hp Hr Gal	Fuel Lb Hp Hr	Temp Air F	Temp Cooling F
8th(2B)	128.03	16,792	2.86	2121	14.30	0.03	28.72	13.66	0.52	46	189
9th(2C)	148.27	16,106	3.46	2114	9.90	0.03	28.73	14.46	0.49	46	190
10th(2D)	163.40	15,521	3.95	1987	8.80	0.03	28.73	15.60	0.45	44	191
11th(3A)	178.50	15,167	4.42	1950	7.80	0.03	28.69	15.87	0.44	46	194
12th(2E)	178.69	14,379	4.66	1950	6.70	0.03	28.68	15.87	0.44	46	194
13th(3B)	182.76	12,489	5.49	1950	4.80	0.03	28.69	16.20	0.43	47	195
14th(2F)	182.90	11,969	5.73	1950	4.60	0.03	28.70	16.32	0.43	47	196
15th(3C)	186.67	10,762	6.51	1950	3.80	0.03	28.70	16.65	0.42	47	195
16th(3D)	188.27	8,916	7.92	1950	2.50	0.03	28.71	16.80	0.42	47	196
17th(3E)	186.38	7,450	9.39	1950	1.80	0.03	28.71	16.58	0.42	47	196

Fuel Consumption Characteristics (Unballasted) Front Drive Engaged

Click column headers to sort

Power	kW	Pull (lbs)	Pull (kN)	Speed	km/h	RPM	Slip	DEF lb/hp	Air °F	Barometer Inch Hg	Condition	Fuel Hp Hr Gal	Fuel Lb Hp Hr	Temp Cooling F
168.77	125.85	12,963	57.66	4.88	7.85	2100	5.30	0.03	46	28.69	Maximum Power—11th(3A) Gear	15.21	0.46	193
130.95	97.65	9,722	43.25	5.05	8.13	2127	3.30	0.03	42	28.73	75% of Pull at Maximum Power—11th(3A) Gear	14.84	0.47	187
89.41	66.67	6,495	28.89	5.16	8.30	2136	1.60	0.03	41	28.74	50% of Pull at Maximum Power—11th(3A) Gear	13.39	0.53	184
130.63	97.41	9,678	43.05	5.06	8.14	1506	3.10	0.04	40	28.75	75% of Pull at Reduced Engine Speed—15th(3C) Gear	17.44	0.40	188
89.44	66.70	6,495	28.89	5.16	8.30	1513	1.60	0.03	41	28.74	50% of Pull at Reduced Engine Speed—15th(3C) Gear	16.39	0.43	185

Category: III Quick Attach: None

Single Outlet Set

Sustained Pressure	2,425 psi
Flow Rate (min press)	26.70 gpm
Max Power	N/A hp

Engine

Make	Sisu AGCO Power
Type	Diesel, six cylinder vertical with turbocharger and air to air intercooler and SCR (selective catalyst reduction) exhaust treatment
Displacement	449 cu in (7365 ml)
Compression Ratio	17.8 to 1
Rated Engine Speed	2100 rpm
Air Cleaner	two paper elements and aspirator
Exhaust	DOC (diesel oxidation catalyst) and SCR (selective catalyst reduction) with a vertical muffler
Crankshaft	lengthwise

Chassis

Type	front wheel assist
Steering	hydrostatic
Transmission	selective gear fixed ratio with partial (6) range operator controlled powershift
Speeds	24 forward (26.72 mph max)
Wheelbase	117.80 in (2993 mm)
Front Tread Width	60.9 to 88.8 in
Rear Tread Width	55.2 to 119.0 in
Brakes	multiple wet disc hydraulically operated by two foot pedals that can be locked together
Hydraulic Control	direct engine drive
Unladen Tractor Mass	18,525 lbs ( 8,403 kg )

Consumables

Fuel	No. 2 Diesel
DEF Fluid	32% aqueous urea solution

Tires & Tracks

Rear Tires	Two 520/85R42; **; 14(100) psi (kPa)
Front Tires	Two 16.9R30; **; 18(125) psi (kPa)
Height of Drawbar	19.50 in (495 mm)

Static Weight

Rear	11,280 lbs
Front	7,420 lbs
Total	18,700 lbs
